Gambar / Foto / Photo & Info Sample Mobil Listrik ( Electric Car ) China

Di saat banyak mahasiswa otomotif Indonesia tengah melakukan riset pembuatan mobil listrik, di RRC justru mobil listrik sudah diproduksi massal. Modelnya bermacam macam dan kebanyakan mirip mobil merk ternama yang sudah populer. Bedanya ya di mesin penggerak tenaga elektrik dan bahan body mobil dari fiber agar ringan. Soal harga di China mulai sekitar Rp. 15.000.000 ke atas. Untuk sekedar sebagai kendaraan pribadi tambahan kebutuhan dalam kota masih bisa diandalkan. Kemampuan menaklukkan tanjakan saat dalam kapasitas angkut penuh, maksimal derajat kemiringan tanjakan yaitu 30 derajat ke bawah.

Product Specifications:

• Maximum speed: 90 to 100km/h
• Maximum range per charge (levelground, 50km/h): 120km
• Maximum gradability: 20%
• Curb weight: 1330kg
• Loading capacity: 300kg
• Seating capacity: 4 persons
• Size (L x W x H): 3,400 x 1,575 x 1,670mm
• Wheel base: 2,335mm
• Track base: 1,360/1,355mm
• Tire specification: 165/65R13
• Motor controller: 15kW BLDC motor controller system
• Battery: maintenance-free lead-acid battery

Product Specifications:

• Passenger capacity: 2
• Range per charger: ≤140km
• Axle distance: 2,000mm
• Wheel distance: 1,205 or 1,200mm
• Loading ability: 880kg
• Controller system: AC controller (DSP)
• Battery: 72V (closed and maintenance free battery)
• Motor system: 6kW AC motor
• Steer wheel system: single-stage rack and pinion steering system, automatic rocker compensating function
• Brake system: hydraulic and mechanist double brake
• Rear and front axle system: front axle for direction and rear axle drive
• Charger: 110 to 220V Chinese charger
• Body and frame: steel strike out body and professional car frame
• Front suspension: independent suspension
• Rear suspension: leaf spring non-independent suspension
• Tire: vacuum tire
• Chassis: profession car chassis
• Climb ability: ≤30% (loaded)
• Maximum speed: ≤5kph
• Seat: soft seat as normal truck
• Size: 3,500 x 1,450 x 1,750mm

Product Specifications:

• Body: steel framework + fiber glass
• Brake system: four wheels hydraulic drum with parking brake by foot
• Chassis: integral type high strength structural steel + pickling phosphate treatment
• Light system:
  • Front headlights
  • Front/rear turn signals
• Side turn signals
• Combination tail lamp
• Suspensions:
  • Front: independent coil spring with drum hydraulic shock absorbers
  • Rear: laminated leaf springs non-independent with drum hydraulic shock absorbers
• Minimum ground clearance: 120mm
• Wheelbase:
  • Front: 1,210mm
  • Rear): 1,200mm
• Maximum loading weight: ≤1.2T
• Maximum speed: 30 to 35kph
• Braking distance: ≤4.0 m
• Minimum turning radius: ≤4.4 m
• Maximum climbing capability: 25%
• Range (loaded): 80 to 100 km
• Tire: 145R12C, 6PR, tubeless
• Overall dimensions: 3,650 x 1,490 x 1,825mm
• Net weight (include batteries): 1,260kg

Product Specifications:

• Dimensions: 4,050 x 1,670 x 1,465mm
• Weight: 953kg
• Wheelbase: 2350mm
• Maximum speed: 55km/h
• Distance per charging: 120km
• Gear: step-less
• Tire: 160/70 R13
• Motor: 60V/4kW/200Ah
• Battery: 6V 200Ah 10pcs
• Charging time: 8 to 10 hours
• Brake: disc/drum
• Colors: silver, blue, red, black, and white
• Climb ability: 25 degrees

Product Specifications:

• Dimension: 4,100 x 1,480 x 1,790mm
• Ground clearance: 150mm
• Wheelbase: 2,370mm
• Max speed: 55km/h
• Wheel type (front/rear): 165/70R13
• Weight of empty vehicle (no battery): 787kg
• Seating capacity: 2 persons
• Power: 72V DC, (brush) 6kW
• Battery: 12V, 150Ah (6 pieces)
• Charger: 72V, 20A
• Controller: 72V
• Distance per charge: ≥110km

Product Specifications:

• Length: 2,740mm
• Width: 1,480mm
• Height: 1,565mm
• Wheelbase: 1,715mm
• Motor: 60V AC, 4kW
• Battery: Assay 6V, 180Ah maintenance-free (gel)
• Battery number: 10 pieces
• Battery life: more than 800 times
• Charging time: 8 to 10 hours
• Charger in car: 220V/50-60Hz, 25A
• Drive way: rear wheel drive
• Climb ability: 25%
• Max speed: 45km/h
• Distance per charging: 200km
• Suspension: independent
• Brake system: drum/drum

Product Specifications:

• Dimensions: 3,618 x 1,563 x 1,533mm
• Ground clearance: 150mm
• Wheelbase: 2,335mm
• Max speed: 85km/h
• Wheel type (front/rear): 155/65R13
• Net weight: 790kg
• Seating capacity: 5 persons
• Power: 120V AC, 8.5kW
• Battery: 12V, 115Ah (10 pieces)
• Charger: 110V /50 to 60Hz
• Controller: 120V
• Distance per charge: ≥150km
• Battery type: lead-acid
